PALADIO LENS 35

DIRECT / INDIRECT | SINGLE LUMINAIRE

1130 | 35 | 70

PALADIO LENS 35 | DIRECT / INDIRECT as the single linear luminaire version is available in 7 lengths from 1.1 m up to 3.9 m as pendant luminaire.

Luminaires in the PALADIO LENS series have highly efficient mini lens reflectors on the direct luminaire side with a 60° beam angle, UGR19, CRI>90, efficiency 80%. The lenses are integrated into the aluminium luminaire housing in groups in specific louvres. Additional ceiling illumination is provided by opal diffusers arranged in sections on the indirect luminaire side.

This innovative system combines the advantages of lenses and reflectors, with the recessed lens taking over the task of luminous flux distribution, while the reflector reliably reduces the resulting lateral glare. Due to these extremely low glare values, the luminaire complies with the EN 12464-1 standard.

35 mm wide aluminium profile with high-quality brushed and anodised surface in different colours. PALADIO WOOD: PALADIO single luminaires are also available with selected, high-quality wood veneers. Pendant, surface mounted and recessed mounted versions are available.

Practical added value of the PALADIO: aluminium profile with integrated diffuser and technical unit integrated into the luminaire itself. This eliminates the need for a separate canopy or technical unit, which must be in or on the ceiling.

The PALADIO can be used as an individual single luminaire or extended to create complex lighting structures, as a system luminaire using PALADIO CONNECT connecting elements.
